mobile jaw crusher

The details of the equipment are highly restored to the engineering characteristics-there is an adjusting device (adjustable discharge particle size) at the connection of the jaw plate of the crushing host, and there are obvious wear marks on the surface (simulating the state after long-term crushing of hard materials); the feeder and the crushing host There is a dust cover or baffle at the connection; there are protective barriers on both sides of the conveyor belt, and guide rollers at the ends; the fuselage frame is welded by thick metal profiles, the surface is printed with equipment model and safety warning signs (such as "pay attention to rotating parts" and "protective equipment must be worn"); the surface of track link or tire has clear texture, and the contact part with the ground has slight indentation;

Hitachi Excavator

Strictly follow the mechanical principle design of excavator-the upper turntable and the lower chassis are connected by slewing bearing, which can simulate the real rotation function; The boom, stick and bucket of the working device are driven by hydraulic cylinders, and the joints are connected with clear pin shafts and bearing details to restore the flexion and extension trajectory during excavation. The crawler chassis is composed of metal chain links, driving wheels, guide wheels and roller wheels. The chain link texture and crawler tooth structure are clear, the supporting equipment is stable, and the overall structure conforms to the design principle of "power priority and accurate operation" of construction machinery.

lunar probe

The lander design is equipped with a variety of scientific instruments (such as soil analyzer, mass spectrometer, panoramic camera, etc.), and the structure is equipped with landing buffer system, solar panel energy supply device and communication antenna to adapt to the extreme environment of the lunar surface (low temperature, vacuum, radiation, etc.).

Ball valve

It contains a cylindrical or spherical valve body (as the shell of the fluid channel), with a ball with a through hole inside (core control component, the through hole matches the diameter of the pipe), the ball is connected with the external handle through the valve stem, and both ends of the valve body are equipped with Flange or threaded interface (used to connect the pipeline, there are sealing grooves or gasket marks at the interface). The handle is rod-shaped or butterfly-shaped, and the valve can be fully opened/fully closed by rotating 90 °. Some models may include limit devices (to ensure accurate rotation angle).

Realistic Axe

The wedge structure of metal forging is divided into sharp cutting edge (curved cutting edge, thin and sharp edge), heavy axe back (for percussion), and hole groove connecting axe handle (mortise or metal hoop fixing). The surface may have hammer marks, corners or brand logos (such as cast characters/patterns) left by forging.

Z-type cable car

Advantages of structural mechanics: The Z-shaped polyline structure is supported by segments to disperse the force, which saves more space than the linear type, while improving the overall stability, suitable for scenes requiring vertical or inclined lifting (such as small cargo transportation, space partition lifting). Industrial style aesthetics: the naked frame, neat broken lines and mechanical details (such as connectors and sliding rails) are integrated, presenting a coarse and delicate industrial retro style. The lines are simple but full of power, becoming the visual focus in the space.

Old tire inflation pump

vintage tire inflator

LOMO five-axis universal Fedorov stage

Portable gantry crane

Portable gantry crane is a kind of light and efficient lifting equipment, which is widely used in industrial production, logistics storage, construction and outdoor engineering. Its core components include foldable gantry, lifting mechanism, operating mechanism and control system. The use of lightweight and high-strength materials, such as aluminum alloy, reduces its own weight and is easy to carry and move. Its design allows quick assembly and disassembly and is suitable for flexible transfer between different sites. It has a variety of application scenarios, including material handling inside the workshop, cargo lifting for outdoor projects, lifting items for exhibitions and temporary activities, etc. A low cost, high efficiency lifting solution is provided.

Volvo L220H wheel loader

Volvo L220H is a large wheel loader, designed for heavy-duty operations, widely used in mining, construction, material handling and other fields. L220H is equipped with Volvo's efficient engine, which provides powerful power output and excellent fuel efficiency, and adapts to various complex working conditions. The cab design pays attention to the comfort and convenience of the driver, and is equipped with an advanced suspension system and an ergonomic seat, which reduces the fatigue of the driver due to long hours of work.

Hitachi zx-200 Medium Excavator

Marcy Ferguson 35 Tractor

Massey Ferguson 35(Massey Ferguson 35) is an old-fashioned multi-purpose tractor, produced from 1960 to 1965. The test power of the tractor is 32.13 horsepower (24.0 kW), and the test power of the PTO (power take off shaft) is 37.04 horsepower (27.6 kW). The hydraulic system has a capacity of 8 gallons (30.3 liters), a pressure of 2800 psi(193.1 bar), and a pump flow of 3.5 gpm(13.2 lpm).

Kobelco SK210LC-10 long arm excavator

The SK210LC-10 long arm excavator is a high-performance construction machine designed for engineering that requires long-distance excavation and handling. It is equipped with a 15-meter-long arm, which can operate in a larger area, and is very suitable for river cleaning, earthmoving and other tasks that require long-distance operation.

Hitachi ZX300-7 Medium Excavator

Hitachi ZX300-7 medium excavator is an efficient and versatile construction machinery suitable for various tasks. It not only performs well in terms of operating comfort and safety, but also significantly reduces operating costs. The 197 kW Isuzu 6HK1X engine is equipped with the advanced hydraulic system TRIAS III.

science fiction thermometer

Generator equipment

German FK C 48 typewriter

It is a classic mechanical typewriter, produced by the famous German typewriter manufacturer HeinrichErnemann. Known for its rugged and precise mechanical design, it was ideal for mid-20th century office and home use. Using the classic "QWERTY" keyboard layout, the character keys are divided into three lines, in addition to the basic character keys, but also equipped with space, carriage return, line feed and move up and other function keys. The design pays attention to the user experience, and the typing method is hard typing, that is, letters or characters directly hit the roller, which belongs to the mechanical typing method. The metal body and fine craftsmanship made it very popular at the time.

Metabo vintage electric drill

Metabo is a German power tool manufacturer with a long history, founded in 1924. Its vintage electric drill was one of the brand's early products, embodying Metabo's strict requirements for tool quality and durability. Robust metal housing and precise mechanical design provide stable drilling performance. It is known for its high output torque and motor overload resistance. The design focuses on ergonomics to ensure the comfort and convenience of operation for users during long-term use. It is widely used in the industrial field, and it is also favored by professional craftsmen because of its excellent performance and reliability.

1930 s typewriter

It is known for its classic mechanical design and function. It has a solid metal construction and a classic keyboard layout. The design focuses on durability and reliability, and can withstand long-term use. With its elegant appearance and practical functions, it became a common equipment in offices and homes at that time. In addition, the 1930 s also saw the initial development of electric typewriters, although they were not widely available at the time. These typewriters were not only important office tools at the time, but also laid the foundation for later computer keyboard design.

SWIFT SW380B Microscope

Is a high quality vertical binocular microscope, widely used in biological research, academic education and medical diagnosis and other fields. It has a double-layer mechanical stage to provide a stable observation platform. Its optical system uses a high-quality lens and objective combination to ensure a clear, high-contrast observation image. Equipped with an adjustable LED lighting system, it can provide uniform and stable lighting, so that the sample is fully illuminated during observation. Supports magnification from 40 times to 2500 times to meet different observation needs. Its design focuses on user-friendliness, easy operation, suitable for users of different ages and technical levels.

Portable generator

It is a kind of equipment that converts mechanical energy into electrical energy, which is widely used in power production, industrial manufacturing, transportation and other fields. Its basic working principle is to use the phenomenon of electromagnetic induction, that is, to generate current through a rotating magnetic field or a conductor coil. Mainly divided into two categories of DC generators and AC generators. Performance parameters include rated power, rated voltage, rated frequency, etc., which determine the output capacity and scope of application of the generator. When using a generator, it is necessary to select the appropriate model according to actual needs and ensure its stable operation to provide reliable power supply.

Titanic anchor

An important part of this famous cruise ship, each anchor weighs a staggering 15 tons. Physically fixed the Titanic and became part of its history. The construction of the Titanic began on March 31, 1909, and was launched on May 31, 1911. It sank after hitting an iceberg during its maiden voyage in April 1912, killing more than 1500 people. It was not until 1985 that the sunken ship was discovered by humans. Its anchor and other debris lay quietly on the bottom of the Atlantic Ocean. It is a symbol of engineering technology in that era and witnessed a great tragedy in the history of human navigation.
